PixaPro LED100D MK II Review

PixaPro LED100D MK II Review

Often touted as a cheaper version of the Aperture 120D for UK buyers, how does the PixaPro LED 100D Mk II hold up?

You watch the video review for visual examples of the light in use, or if you prefer, you can find the written article below (originally published in 2016).


The Review

Often you can be in a location where the use of Fresnel lighting is not an option. Perhaps the area is too compact, and the setup of the lights and their heat output will be too extreme for your other equipment and actors. To counter the heat of the tungsten Fresnel’s, you can look at acquiring an LED version of that light. Now, LED fresnels quickly run into thousands of pounds. However, for just a few hundred pounds, you can look at getting the behemoth tool of the PixaPro LED 100 MK II.

Recently I’ve been using the Pixapro LED100D Mk II daylight light, which is priced at £279.

Design

This is not going to break easily; it is going to have to endure a lot of stress before the housing gives way. Given the power output, the light is very compact compared to other lights that provide the same Illuminance. At the front, there is an S-type fitting to which many accessories can be attached. The light comes with a reflector dish, but there is also an umbrella that can be purchased from Pixapro, this turns to the light into a nice softbox. Great alternative if you don’t have access to diffusion sheets.

Image of the Pixapro LED100D Mk II with an umbrella attachment.

Underneath the light, we have a plug for a v-mount battery adapter. The battery supplied can will last for one hour running time at full power, and the adapter has a velcro strap, which will allow you to attach it to a light stand easily.

Image of the underside of the Pixapro LED 100D showing the plug for a v-mount adapter.

On the back, there is an operation dial. There are two-channel selections for wireless operation, and then the dial operation for dimming. The brightness can be increased in decimal increments all the way from 1.0 to 6.0. I will say, if I have to give this light a negative, it is the dial operation. I would love to be able to go from 1.0 to 6.0 in a single turn.

The back of the Pixapro LED100D Continuous Light with a hand controlling the dial.


The light itself is produced from an integrated LED chip, which will last for around 30,000 working hours before self-destructing.  This is a bright light—the LUX rating of 42,000 at half a meter, and 15,000 at one meter. I recently used this on my short film to blast in light from the outside to mimic the sunlight, and as you can see from the results [watch video], it worked perfectly. There are an overall consistency and brightness with the light; it’s been an excellent tool for green screen work. Although the beam angle at 45° doesn’t make this a one-stop-shop for complete light coverage, as you cannot specifically direct the light, this can be powered with both AC/DC voltage inputs.

With being able to produce so much brightness, you would assume the light gets hot, but no. Of course, the LED itself becomes hot, but the housing doesn’t because of the built-in fan, which is near enough silent. The light has a CRI rating of ≥94, which is going to help dramatically reproduce accurate color in your video and photographs. No blotchy skin tones or offset greens here.

Now, a problem I’ve always had with tungsten and other LEDs is the flicker you encounter as you start to increase your frame rate and shutter speed for slow motion. With this light, you can work up to 900fps before you begin to see any flickering. Along with the crazy Illuminance, the light is an excellent tool for slow-mo. It’s a great light, sturdy, very powerful and for the low price of £299 it’s a complete steal, it really is. I think this is no my go-to light for when I need to blast in illumination from outside.

Specifications

Direct from Pixapro, here are the specifications.

ModelPIXAPRO LED100D MKII
Power Output100W
Luminous Flux10,000 lm
Brightness/Illuminance42,000 lux @ 50cm (15,000 lux @ 1m)
LED TypeIntegrated LED Chip
Colour Temperature5600k
Beam Angle45°
CRI≥94
Power Range10-100%
LED LifeApprox. 50,000 Hours
Remote ControlYes (Sold Separately)
Dimensions275mm x 130mm x 220mm
90cm Umbrella Softbox
Diameter90cm
ShapeOctagonal
Layers of Diffusion2
Gris size4cm
FittingS-Type (Interchangeable)
260cm Stand
Min. Height111cm
Max. Height260cm
Max. Load Capacity5kg
Tube Diameter30cm/25cm/22cm/19cm
Spigot Size5/8”
Air-CushionedYes
Material

AluminumYou can acquire a LED100D Mk II kit here.

Posted by Lewis McGregor

Lewis McGregor is a filmmaker, photographer and online content creator from Wales.
